4YZP-4FGD
1. The new plate-type header reduces grain breakage and is suitable for harvesting waxy and red-core corn. It allows your vehicle to operate across regions from Henan to Northwest China and Inner Mongolia, extending operation time, increasing workload, and maximizing profits.
2. The header's main drive leads the industry with its gearbox transmission! Gearbox transmission! Gearbox transmission! Operators no longer need to worry about chain elongation or belt slippage during operation, achieving true maintenance-free operation and greater peace of mind.
3. The 2024 Jin Dafeng plate-type corn header features a dual-tone cab, showcasing a youthful and lively image. With a 38cm increase in width and a 5cm increase in length, it offers more spaciousness. For operators frequently working across regions, this provides better rest and enhanced practicality.
4. The ergonomic air-suspended seat and the linked height adjustment of the control panel and seat ensure comfort even for operators weighing over 200 jin. After a day's work, they'll experience no backache, numbness, or leg pain, enjoying the fruits of their labor.
5. The power system utilizes a 280-horsepower, high-quality six-cylinder engine (Yuchai or Dongfanghong optional), delivering high torque at low speeds for powerful harvesting. The upgraded 400-liter fuel tank ensures extended range and operation for large areas.
6. The dual grain bins offer ample storage, and an optional grain elevator and grain recovery bin are available. The added grain elevator fan effectively filters impurities from the corn kernels, ensuring cleaner grain storage. The 260L grain recovery bin serves dual purposes: storing corn kernels directly or, by adjusting a rotating handle, transferring kernels to the ear box. This eliminates the need for frequent stops to empty the recovery bin, saving time and effort.
7. An optional mechanical conveyor (ear elevator) can be installed between the peeler and the grain bin, allowing for slower filling and increasing harvesting by 50 meters per stop for unloading, reducing downtime and increasing efficiency.
| Model | 4YZP-4FGD | ||
| Structural type Structural type | / | Wheel type, ear picking, peeling, straw returning wheel type, ear picking, peeling, straw returning | |
| Dimension (L×W×H) | mm | 7600×2800×3490 | |
| Mass of complete machine | kg | 9000 | |
| Header Header | Header type | / | horizontal type |
| Number of operating lines (number of channels) | Rows | 4 | |
| row pitch | mm | 560 | |
| Working breadth | mm | 2370 | |
| Type of ear picking mechanism | / | Picking Plate Picking Plate | |
| Number of ear picking rollers | Pieces | 8 | |
| lift conveyer lift conveyer | Layout of ear elevator | / | Center placed Center placed |
| Structural type of ear elevator | / | Chain scraper type Chain scraper type | |
| Engine Engine | Model | / | 280Gâ ¢ |
| Type | / | Six-cylinder, in-line, four-stroke, high-pressure common rail Six-cylinder, in-line, four-stroke, high-pressure common rail | |
| Qty of cylinders | / | 6 | |
| Rated power | HP/KW | 280HP/205.9KW | |
| Rated speed | r/min | 2300 | |
| Peeler Peeler | Type of stripping mechanism | / | Rubber roller Rubber roller |
| Number of stripping rollers | Pieces | 20 | |
| Field returning machine Field returning machine | Type | / | Swing blade type Swing blade type |
| Location of straw crushing and returning mechanism Location of straw crushing and returning mechanism | / | Between front and rear tires Between front and rear tires | |
| Working Width of Straw Crushing and Returning Mechanism Working Width of Straw Crushing and Returning Mechanism | mm | 2300 | |
| Type of cab | / | Luxury air-conditioned cab Luxury air-conditioned cab | |
| Type of transmission mechanism: Type of transmission mechanism: | / | Mechanical gearbox + hydrostatic continuously variable transmission Mechanical transmission+hydrostatic stepless transmission | |
| Driving Typeï¼ | / | Two drive system | |
| Mini clearanceï¼ | mm | 240 | |
| Working speedï¼ | km/h | 2-6 | |
| Drive wheel trackï¼ | mm | 1920 | |
| Guide wheel trackï¼ | mm | 1650 | |
| wheel baseï¼ | mm | 3000 | |
| Drive wheel tire specificationsï¼ Drive wheel tire specificationsï¼ | / | Radial tubeless tyre 15R24 149A8 R-1 Radial tubeless tyre 15R24 149A8 R-1 | |
| Specification of guide wheel tireï¼ Specification of guide wheel tireï¼ | / | Diagonal Tubeless Tire 400-60-15.5-16PR-I-3E Diagonal Tubeless Tire 400-60-15.5-16PR-I-3E | |
| Productivityï¼ | hm²/h | 0.4-0.7 | |
| Grain tankï¼ | m³ | 3.2 | |
| fuel tank capacityï¼ | L | 420 | |
| imageï¼ imageï¼ |    | ||
| Description of configurationï¼ Description of configuration: | Plate-type turret wheel header, row pitch 560, Yuchai A08-280 HP six-cylinder engine, with blowback fan, no air pump, front pulverizer, center returning machine 2300, solenoid valve, one lever operation, one pump and one motor hydraulic walking, front brake, rear brake, 20 roll height adjustable peeling machine, luxury driving room, suspension control box, full bin image, reversing image, grain lifter, impurity exhaust fan, hydraulic main clutch, power output, Beidou positioning, air conditioner and mechanical ear lifter. Plate-type turret wheel header, row pitch 560, Yuchai A08-280 HP six-cylinder engine, with blowback fan, no air pump, front pulverizer, center returning machine 2300, solenoid valve, one lever operation, one pump and one motor hydraulic walking, front brake, rear brake, 20 roll height adjustable peeling machine, luxury driving room, suspension control box, full bin image, reversing image, grain lifter, impurity exhaust fan, hydraulic main clutch, power output, Beidou positioning, air conditioner and mechanical ear lifter. | ||
| Product Features Product Featuresï¼ | GOLD Dafeng "4YZP-4FGD self-propelled corn harvester has compact mechanism and small turning radius;Hydraulic walking, one-lever operation, flexible turnaround.The new non-row roller header is applicable to different maturity periods of corn, with a wide range of adaptability. GOLD Dafeng "4YZP-4FGD self-propelled corn harvester has compact mechanism and small turning radius;Hydraulic walking, one-lever operation, flexible turnaround.The new non-row roller header is applicable to different maturity periods of corn, with a wide range of adaptability. | ||
| 1.Strong power: 280 HP engine, strong power: light load, medium load and heavy load three-gear frequency conversion, energy saving and fuel saving. 2.Comfortable operation: one pump, one motor, hydraulic walking, original built-in air conditioner.Multi-function electronic control handle, upright driving instrument, easy for the driver to read.Shifting to the reverse gear will automatically lift the returning machine, making driving safer; 3.Super-strong chassis: the frame adopts 16 sections and triangular support beam structure, which is resistant to bumping and impact.The driving wheel adopts radial tire, with stronger grip.Widened guide wheel, with good anti-seffect. 4.High-efficiency operation: new plate header, forced stem pulling, small grain loss during feeding.With a long front tip, lodging corn can be harvested, and the reel angle can be adjusted, which is applicable to a wide range of row spacing;High-efficiency 20-roller stripping machine with high stripping rate; 5.Convenient maintenance: the transmission chain adopts the automatic lubrication device, and the stripping machine and fan bearings adopt the centralized oil injection method, which saves time and mind. 6.Intelligent material technology: after scanning code and registering mobile APP, it can be interconnected with the harvester through mobile bluetooth for intelligent control and troubleshooting. 1.Strong power: 280 HP engine, strong power: light load, medium load and heavy load three-gear frequency conversion, energy saving and fuel saving. 2.Comfortable operation: one pump, one motor, hydraulic walking, original built-in air conditioner.Multi-function electronic control handle, upright driving instrument, easy for the driver to read.Shifting to the reverse gear will automatically lift the returning machine, making driving safer; 3.Super-strong chassis: the frame adopts 16 sections and triangular support beam structure, which is resistant to bumping and impact.The driving wheel adopts radial tire, with stronger grip.Widened guide wheel, with good anti-seffect. 4.High-efficiency operation: new plate header, forced stem pulling, small grain loss during feeding.With a long front tip, lodging corn can be harvested, and the reel angle can be adjusted, which is applicable to a wide range of row spacing;High-efficiency 20-roller stripping machine with high stripping rate; 5.Convenient maintenance: the transmission chain adopts the automatic lubrication device, and the stripping machine and fan bearings adopt the centralized oil injection method, which saves time and mind. 6.Intelligent material technology: after scanning code and registering mobile APP, it can be interconnected with the harvester through mobile bluetooth for intelligent control and troubleshooting. | |||
